Overview
Add a touch of style and functionality to your dashboard, control panel, or DIY electronics project with this 12V 20A Translucent Toggle Switch with Light.
This SPST (Single Pole Single Throw) switch offers ON-OFF control with a built-in neon lamp indicator that glows when the switch is ON, making it ideal for automotive, marine, and hobby electronics applications.
Designed for easy installation, the switch fits into a 12mm mounting hole and features three copper terminals for power, load, and ground connections. The translucent lever is available in multiple vibrant colors — red, yellow, green, blue, and black — giving your setup a modern illuminated look.
Perfect for controlling LED lights, fans, accessories, or any 12V DC circuit, this toggle switch combines durability, visibility, and style in one compact form.
Specification
| Specification | Details |
|---|---|
| Model | ASW-13D |
| Switch Type | SPST (Single Pole Single Throw) |
| Contact Type | ON-OFF |
| Rated Voltage | 12V DC |
| Rated Current | 20A |
| Number of Pins | 3 Pins |
| Bulb Type | Neon Lamp (Illuminated) |
| Mounting Hole Diameter | 12mm |
| Mounting Thread | M12 × 0.75 |
| Dimensions | Approx. 27mm height (excluding terminals) |
| Body Material | Plastic housing with copper terminals |
| Handle Angle | 24° toggle range |
| Available Colors | Red, Yellow, Green, Blue, Black |
| Application | Automotive, Marine, DIY Electronics, Power Control |
Pinout
